Top-specified, totally new freeride weapon of choice. With the 180mm front and rear travel delivered by the Fox 38 fork and Fox DHX shock, it’s definitely time to look for the expert-only bikepark trails and the toughest freeride lines. Super solid Dartmoor Shield Wide wheels, bulletproof Maxxis DHF tires with DH casing, and 4-piston brakes let you forget about the limits.
MAIN FEATURES
- 180/180mm front/rear suspension travel
- Super solid Dartmoor Thunderbird aluminum frame with 180mm travel, boost rear end, and SRAM UDH hanger
- 1.8" tapered head tube with 68mm fork crown and 60mm bottom headset bearing to ride even on the most challenging bikepark lines
- Fox 38 performance series fork with Grip damper and 38mm upper legs
- Fox DHX Factory series shock
- 11-speed Shimano Deore 5100 drivetrain with Sunrace 11-51T cassette
- Powerful Magura MT5 brakes with a 4-piston caliper and 203mm rotors
- Oversized 35mm cockpit with all-new 810mm wide Viper handlebar and short Viper stem
- Bump proof Shield Wide rims with Maxxis DHF tires with DH casing
Specification
COLOR
glossy Metallic Silver
FRAME
glossy Metallic Silver, AL 6061-T6, travel 180mm
FRAME SIZE
Medium, Large
WHEEL SIZE
27.5"
FORK
Fox 38 Performance 27.5", Grip, Boost, travel 180mm, crown 68mm, axle 15mm, tapered
SHOCK
Fox DHX Factory, 225x75mm, Trunnion, coil 400
SHOCK HARDWARE
22.2x8mm
HEADSETS
Dartmoor Storm OEM
DERAILLEUR
Shimano Deore RD-M5100 1x11
SHIFTER
Shimano Deore SL-M5100-R, 11-speed
BRAKES
Magura MT5N, 4-piston brakes, rotors front 203mm front/rear
CRANKSET
Race Face Aeffect R, 170mm
CHAINRING
Direct mount 34T
CASSETTE
Sunrace CSMS7, 11-51T
CHAIN
KMC X11
PEDALS
without
RIMS
Darmoor Shield Wide 27.5", 32H, F/V, tubeless ready
FRONT HUB
Dartmoor Reel Boost 110x15mm, 32H
REAR HUB
Dartmoor Reel Boost 148x12mm, 32H
TIRES
Maxxis Minion DHF 27.5x2.5, Wire, ST/DH Casing
HANDLEBAR
Dartmoor Viper 810mm, Ø35mm
STEM
Dartmoor Viper, Ø35mm
GRIPS
Dartmoor Roots
SADDLE
Dartmoor Trail v.2
SEATPOST
alu 6061, 30.9x350mm
WEIGHT
16.90kg (w/o pedals)
| size | reach (mm) | stack (mm) | ST (mm) | TT (mm) | eTT(mm) | CS (mm) | HT (mm) | HT angle (°) | eST angle (°) | BB drop (mm) | WB (mm) | standover (mm) | wheel size (") | hub size (mm) | headset type (S.H.I.S.) | BB type (mm) | post diam. (mm) | clamp diam. (mm) | brake mount | max. rotor size (mm) |
| MEDIUM | 445 | 619 | 430 | - | 540 | 430 | 110 | 65 | 81 | 12 | 1206 | 795 | 27.5 | 148x12 | IS42/IS60 | BSA/Euro73 | 30.9 | 34.9 | PM 180mm | 203 |
| LARGE | 470 | 619 | 450 | - | 565 | 430 | 110 | 65 | 81 | 12 | 1231 | 795 | 27.5 | 148x12 | IS42/IS60 | BSA/Euro73 | 30.9 | 34.9 | PM 180mm | 203 |
